Aramid Nonwoven Nomex Needle Punched Felt Filter Industrial Air Filters
Baghouse dust collector Nomex Bag Filters D 160mmXL 4500mm Used in Ferroalloy Plant, Refractory plant
Nomex Filter medias
Application of Nomex needle felt filter:
Nomex Filter medias are mainly used in cement industry, asphalt industry, metallurgical industry and tobacco industry for flue gas purification.
Performance of Nomex needle felt filter:
Continuous operating temperature is up to 200°C, instant service temperature is up to 240°C
Fire retardant performance is excellent
Corrosion resistance and alkali resistance is good
Excellent thermal stability, excellent abrasion resistance and flexural resistance Hydrolysis resistance is poor, frequent SOx and vapor in flue gas or dew point will greatly reduce its service life
Description:
All types of dust filter bags for dust collector system ,Various coatings and finishing on the fabrics of the dust filter bags can be applied to either side of the to enhance cleaning and efficiencies of dust collector system , as well as prolonging service life. Ground wire, anti-collapse rings, and other options can easily be incorporated into bag construction. can custom fabricate various types of attachments to work with your specific shaker mechanism, whether a loop, eyelet, grommet, or other device
All types of dust filter bags for dust collector system Dust filter bags are carefully fabricated and sized to ensure ease of installation and change-out. Generally, dust collector filter bags are designed to be mounted and gasketed firmly into place with a snap band, corded cuff, or clamp to ensure dust type seal.
Filter bags, dust collector bag ,dust filter bag , dust bags, filter socks, – they all mean the same thing: An industrial grade fabric filter made from heavy duty material, all textile based, used in dust collecting systems, in either process filtration or pollution control.
Good Quality Industrial Polyester Dust Collector Filter Bag
1 – Good quality polyester filter material made with advanced machinery
2 – Accordingly adjusted technical process
3 – Strict raw material control and products quality control
4 – Competitive price
Tailor service ,just let us know your request ,we will give exact recommendation .
Steel plant furnace smoke filter Nomex bag filter D 160XL 4500MM
What kind of product that showed on our website do you need? PTFE fiber, PTFE Sewing thread, dust filter cloth and dust filter bag?
If you want buy filter cloth or felt and filter bag, tell me if you need membrane lamination.
The size of dust filter and collect bag.
Is it a revise air or pluse jet?
Flat Dimension.
Specs on Material.
Is it a Top or Bottom Load Collector?
Your working conditions such as temperature resistance, chemical resistance.
Technical specification of Nomex needle felt filter :
Article Name
Nomex needled felt
Ingredients
Fiber
100% Nomex
Scrim
100% Nomex
Weight
g/m2
500
Thickness
mm
2.1
Density
g/m³
0.24
Permeability
L/dm2.min
150
Tensile breaking
strength(N/5cm)
Warp
≥800
Weft
≥1000
Elongation @200N/5cm
Warp
<5
Weft
<5
Maximum shrink
of 90 mins
Temperature(°C)
250
%
≤1
Service Temperature(°C)
Continuous
200
Instant
240
Finishing
Singeing, calendaring.Water and oil repellent treatment
